1. Introduction
Activated carbon filter cartridge, processed with high technology and special
procedures and made mainly from selected nut shell carbon and coal activated
carbon with auxiliary edible adhesives, is an integration of absorption, filter, i
nterception and catalysis. It is an ideal product in liquid and air cleaning industries
because of its following functions: a) able to remove organic compounds, remaining
chloride and other radioactive matters in water; b) able to decolorize; c) able to deodorize.
With the most advanced technology and full automatic injection molding device from Taiwan,
end cap for carbon filter cartridge is produced by Xincheng according to International standards
by injecting Taiwanese high polymer materials and TPR simultaneously, which guarantees that
the gaskets will never fall apart. The delicate and safe end cap overcomes the difficulty that
haunts all the time: poisonous end covers, strange smells, falling gaskets. etc.
2. Applications
Drinking water filtration;
Electroplating liquid
Industrial water filtration
3. Materials
Filtration Materials: coal carbon, fruit shell carbon and coconut shell carbon;
End caps: Taiwanese high polymer materials, polypropylene
Gasket: TPR, nitrile rubber
Grids: polypropylene
Core: polypropylene
4. Specifications (Unusual size can be manufactured as per the order)
Length: 5¡å¡¢10¡å¡¢20¡å¡¢30¡å¡¢40¡å£»
OD: 65mm¡¢70mm¡¢115mm£»
ID: 28 mm¡¢30 mm£»
Precision: 5 ¡« 10¦Ìm
5. Main Performances:
Working temperature¡Ü52¡æ; Max. pressure-resistance:0.4Mpa£»
Max flow: 5L/min
6. Models
Example: CTO- M-5-10
Explanations:
CTO£ºCompressed activated carbon filter cartridge
CTOC£ºCompressed activated carbon filter cartridge with core
M: filtration material M: coal carbon; G: fruit carbon; Y: coconut shell
5: Filtration precision: 5¡ª5¦Ìm£» 10¡ª10¦Ìm
10: Filter length: 10¡ª10¡å£» 20¡ª20¡å£» 30¡ª30¡å£» 40¡ª40¡å
|
